Why is polyester needle felt the first choice for industrial dust removal? Analysis of product advantages

1. Advantages of Polyester Needle Punched Felt for Industrial Dust Removal

• Excellent Balance of Filtration Efficiency and Air Permeability

3D Structure Advantages:

Three-dimensional fiber network structure formed through a precision needle punching process

Porosity as high as 70%-80%, far exceeding traditional woven filter media

Surface pore size adjustable from 5-30μm to meet varying precision requirements

Measured Data Comparison:

PM10 Filtration Efficiency ≥99.5%

Airflow maintained in the ideal range of 10-15 cm³/(cm²·s)

Initial resistance of only 50-80 Pa, significantly reducing energy consumption

• Excellent Durability and Economic Benefits

Outstanding Wear Resistance:

Fiber Breaking Strength ≥6 cN/dtex

Dynamic Wear Tests Show 3-5 Years of Life, More Than Double the Lifespan of Traditional Filter Media

• Stable Chemical Resistance

Corrosion Resistance:

pH range 3-11

Excellent resistance to weak acids and bases

Good hydrolysis resistance (RH < 60%)

Special Treatments:

Oil and water repellent treatment (contact angle > 100°)

Antistatic treatment (surface resistance < 10⁹Ω)

PTFE impregnation for enhanced corrosion resistance

• Excellent Temperature Adaptability

Temperature Resistance:

Continuous operating temperature ≤ 130°C

Transient temperature resistance up to 150°C (≤ 30 minutes)

Heat shrinkage <1% (tested at 130°C)

Typical applications:

Cement plant kiln exhaust (120-180°C)

Sintering machine head dust removal in steel plants

Coal-fired boiler flue gas treatment

• Flexible Process Adjustability

Surface Treatment Technologies:

Singeing: Reduces fiber shedding

Calendaring: Improves surface finish

Coating: Enhances filtration accuracy

2. Maintenance Recommendations for Polyester Needle Punched Filter Felt

Inspection and preparation before installation

(1) Check the matching of filter bag and bag cage

Dimension verification: Ensure that the length of the filter bag is consistent with the bag cage, and there is no excessive stretching or wrinkling after installation (stretching rate should be less than 2%).

Bag cage integrity: Check whether the welding points are smooth, without burrs or deformation, to prevent scratching the inner wall of the filter bag.

Sealing test: Air tightness test is required after installation, and the leakage rate should be less than 1%.

(2) System cleaning

Clean the inside of the dust collector thoroughly before installation to avoid welding slag and dust residue that may cause wear of the filter bag.

Check whether the edge of the flower plate hole is smooth and polish with sandpaper if necessary.

Daily maintenance during operation

(1) Optimization of cleaning parameters

Pulse pressure: Control at 0.4-0.6MPa. Too high pressure will cause fiber breakage, and too low pressure will not clean thoroughly. Cleaning cycle: Adjust according to the pressure difference (it is recommended to clean when the pressure difference is ≤1500Pa), avoid frequent cleaning (8-10 minutes interval is appropriate). Cleaning mode: Using "offline cleaning" can reduce secondary adsorption and extend the life of the filter bag.

(2)Pressure difference monitoring

Under normal operating conditions, the system pressure difference should be stable at 800-1200Pa. If the pressure difference continues to rise (>1500Pa), the possible reasons are: Filter bag blockage (need to check the cleaning system) Dust humidity is high (need pretreatment or reduce wind speed) Filter bag surface is hardened (need to be manually cleaned or replaced)

(3) Temperature control

Continuous working temperature: ≤130℃ (short-term temperature resistance 150℃, but not more than 30 minutes).

Overtemperature protection: When the flue gas temperature is >150℃, the emergency cold air valve should be activated or the machine should be shut down to prevent the filter bag from shrinking and deforming due to heat.

Maintenance and care during downtime

(1) Inspection during downtime

Appearance inspection: Check the filter bags regularly (every 3 months) to see if there are any problems:

Wear: Check if the bag opening or seams are damaged (commonly caused by poor bag cage welding).

Crustation: Check if hard lumps form on the surface (caused by dust absorbing moisture or oil).

Corrosion: Check if the fiber becomes brittle (acid and alkali corrosion or high temperature aging).

Cage inspection: If rust or deformation is found, replace it in time to avoid puncturing the filter bag.

(2) Cleaning method

Offline cleaning: Use compressed air to blow back to remove surface dust.

Soak in a neutral detergent (pH 6-8) for 12-24 hours to soften the crusted dust.

Rinse with clean water and let it dry naturally (do not expose to the sun or dry in a dryer).

Contraindications:

Do not use a high-pressure water gun to directly flush (will damage the fiber structure).

Avoid using strong acid or strong alkali detergents (pH <3 or >11 will damage the filter material).
